250KW/H�！� The evaporator adopts abroad low consumption evaporating structure; the second effect self-circulation combines the first effect forced circulation, so it is double effect combination structure which decrease the running cost of the second forced circulation pump and other loss. Compared with domestic equipments (capacity at 300-500tons per day) it can save power by 250KW/H.
◎ Compact structure and optimized layout, short pipe length between the first effect evaporator and the second effect evaporator. this structure can reduce the loss of heat resource. the evaporating way adopts the rising film and falling film both, so the effect of heat transfer is better, the pressure of the steam is low, the temperature of material is low too. Temperature of the first effect is 68℃～70℃ and 38℃～40℃ for the second effect.◎ The draining of cooling system uses frequency conversion to adjust water level of the condenser to save power. To avoid the damage of impact vibration when the water goes to the pump, the water supply adopts vacuum self-priming way which also reduce the power consumption.
